Pre-insulated Pair Coil
Pre-insulated Pair Coil
AirFX Pair Coils are designed to deliver superior performance and quality by utilising chemically cross-linked foam polyethylene insulation attached with a flat embossed polyethylene surface film.
| THERMAL INSULATION PROPERTIES | |
|---|---|
| Density | 35 kg/m3 |
| Tensile Strength | 2.45 N/cm22 |
| Thermal Conductivity | 0.04 W/m.K |
| Moisture Permeability Coefficient | ≥10000μ |
| Water Absorptive Capacity | <0.01 g/100cm2 |
| Thickness Shrinkage at 120±5°C | 3% |
| Heat-Resistant Range | -40°C to 120°C |
| COPPER PROPERTIES | |
|---|---|
| Temper | O or 1/2H |
| Chemical Composition | Cu: 99.9% P: 0.015-0.04% |
| Tensile Strength | 205 MPa (min) |
Cu - Copper, P - Phosphorus
20m Pre-insulated Pair Coil
| Product Code | Copper Pipe (outer diameter x wall thickness) | Insulation Outer Diameter (mm) | Insulation Thickness (mm) | Coil Length (m) | Trade Price (Ex. GST) |
|---|---|---|---|---|---|
| AFX-0609-20 | 1/4" (6.35mm x 0.8mm) 3/8" (9.52mm x 0.8mm) |
24 27 |
8 8 |
20 20 |
POA |
| AFX-0612-20 | 1/4" (6.35mm x 0.8mm) 1/2" (12.70mm x 0.8mm) |
24 35 |
8 10 |
20 20 |
POA |
| AFX-0615-20 | 1/4" (6.35mm x 0.8mm) 5/8" (15.88mm x 1.0mm) |
24 41 |
8 10 |
20 20 |
POA |
| AFX-0915-20 | 3/8" (9.52mm x 0.8mm) 5/8" (15.88mm x 1.0mm) |
27 41 |
8 10 |
20 20 |
POA |
| AFX-0919-20 | 3/8" (9.52mm x 0.8mm) 3/4" (19.05mm x 1.2mm) |
27 44 |
8 10 |
20 20 |
POA |
5m Pre-insulated Pair Coil
| Product Code | Copper Pipe (outer diameter x wall thickness) | Insulation Outer Diameter (mm) | Insulation Thickness (mm) | Coil Length (m) | Trade Price (Ex. GST) |
|---|---|---|---|---|---|
| AFX-0609-05 | 1/4" (6.35mm x 0.8mm) 3/8" (9.52mm x 0.8mm) |
24 27 |
8 8 |
5 5 |
POA |
| AFX-0612-05 | 1/4" (6.35mm x 0.8mm) 1/2" (12.70mm x 0.8mm) |
24 35 |
8 10 |
5 5 |
POA |
| AFX-0615-05 | 1/4" (6.35mm x 0.8mm) 5/8" (15.88mm x 1.0mm) |
24 41 |
8 10 |
5 5 |
POA |
| AFX-0915-05 | 3/8" (9.52mm x 0.8mm) 5/8" (15.88mm x 1.0mm) |
27 41 |
8 10 |
5 5 |
POA |
| AFX-0919-05 | 3/8" (9.52mm x 0.8mm) 3/4" (19.05mm x 1.2mm) |
27 44 |
8 10 |
5 5 |
POA |
